    10 Color Roll To Roll Flexographic Nonwoven Printing Machine High Performance

    Product Description

    Products DescriptionHigh Speed Performance 10 Color Roll to Roll Non Woven Fabrics/Bag Flexo/Flexographic Printing Machine/Press and Paper Packaging Shopping Gift Promotional Bag

    This machine is suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag,vest bag and clothes bag, etc.
    This machine is a ten-color flexography printer,adopts kinds ofplate,specialized in the printing of non-woven fabric,it is an idea equipment for non-woven printing.
    Feature:
    1.Simple operation,flexible starting and accurate chromatograph.
    2.Meter-counter could freely setting the printing quantity according to the requirement,auto stopping when finish or material break.
    3.Adopts netting ink transfer roller,uniform process.
    4.Equipped with reliable drying system,high speed rotation,auto cut out when stop.
    5.360 degree continuous adjustable longitudinal device.
    6.Different printing speed can be met by frequency conversion speed control.

    Machine Data
    ModelEPT10-600EPT10-800EPT10-1000EPT10-1200EPT10-1400EPT10-1600
    Max. Material width650mm850mm1050mm1250mm1450mm1650mm
    Max. Printing width560mm760mm960mm1160mm1360mm1560mm
    Printing color10+0, 9+1, 8+2,7+3, 6+4,5+5
    Printing length11.8''-35.4''(300-900mm)/11.8''-47.2''(300-1200mm)
    Printing cylinder wayHydraulic control up and down
    Drive typeSynchronous belt drive
    Mechanical speed135m/min
    Printing speed30-120m/min
    Anilox rollerCeramic anilox roller 10pcs: Shanghai murata brand 200-800LPI
    Opentype doctor blade10pcs
    Tension systemAutomatic tension controller with magnetic powder brake and clutch
    EPCWeb guide 1pcs
    Register precisionLongitudinal:±0.2mmcrosswise:±0.2mm;
    Color registerBy manual
    Unwind/rewind dia.Φ1200mm
    Material holderAir shaft 3'', 2pcs
    Dry systemElectric heating
    Machine power40kw42kw45kw47kw50kw55kw
    Machine size
    (LxWxH)    		6×2×4.2m6×2.2×4.2m6×2.4×4.2m6×2.6×4.2m6×2.8×4.2m6×3×4.2m
    Machineweight5800kg6000kg6100kg6200kg6400kg6800kg
