Round Flat Twisted Handle Automatic Paper Bag Making Machine New Design High Speed

Product Description

Technical data
This serious automatic paper bag making machine with web, drum head card and paper rope as raw materials, one time complete with handle square bottom paper bag, is the ideal equipment for the rapid production of portable paper bags.

Such as shopping bags, shoes and clothing packaging bags, gift packaging bags, business bags and other varieties of hand-held paper bags.

The machine by hand holding machine will roll of rope and paper roll system arm in arm, arm in arm through the transmission system to put the unit and then will be primary or printed roll paper twine pre point break, patch glue, automatic paste hand wan, again by the host with a hand holding the paper to the edge glue, into the bottom of the cone, cutting, creasing, glue, bag forming and piped out of the bag, the whole process of disposable synchronization is complete.

MODEL	JXP-A220	JXP-A330	JXP-A400	JXP-A460	JXP-A550
Paperdiameter	≤1500mm	≤1500mm	≤1500mm	≤1500mm	≤1500mm
Coreinnerdiameter	Φ76mm	Φ76mm	Φ76mm	Φ76mm	Φ76mm
PaperGSM	70-140gsm	80-140gsm	80-140gsm	80-150g/m2	90-140gsm
Paperbagwidth	120-220mmwithhandle	200-330mmwithhandle	200-400mmwithhandle	240-460mmwithhandle	220-550mmwithhandle
	80-220mmwithouthandle	150-330mmwithouthandle	150-400mmwithouthandle	240-460mmwithouthandle	200-550mmwithouthandle
Papertubelength	191-350mmWithhandle	280-430mmWithhandle	280-550mmWithhandle	300-680mmWithhandle	380-650mmWithhandle
	191-430mmWithouthandle	280-510mmWithouthandle	280-600mmWithouthandle	300-680mmWithouthandle	380-770mmWithouthandle
Bottomwidthofpaperbag	50-120mm	80-180mm	90-200mm	90-260mm	00-210mm
Machinespeed	150pcs/min	150pcs/min	150pcs/min	150pcs/min	100pcs/min
Totalpower	32KW	32KW	34KW	34KW	34KW
Machineweight	13000KG	16000KG	18000KG	18000KG	18000KG
Machinedimensions	12×5×2.5M	14×6×2.5M	15×6×2.5M	15x6x2.5M	15x6x2.5M

New Design High Speed Automatic Round Flat Twisted Handle Paper Bag Making Machine

Packing:

As per export standard, they will also be treated before delivery against damage and rusting.

After-sales Service:

Online support, Video technical support, Free spare partsand etc.

Warranty:

One year.During the warranty period, we provide free replacement of damaged parts due to quality problems. All failures caused by improper use of the buyer (including unauthorized modification of PC and touch screen built-in software) are not within the scope of the warranty. (Except for the vulnerable parts of wearing parts)
